Polyurethane
Selang PU 98 MB-Longlife® Import Italy & High Quality
Selang PU (Flexible Linear Hose) dengan tingkat 98 ShA. Selang Polyurethane 98 MB-Longlife® ini banyak digemari karena sangat fleksible, serta memiliki sudut lipat atau bending radius yang kecil. Selang pneumatik ini juga memiliki ketahanan yang baik terhadap abrasi.
Features
Selang pneumatik ini terbuat dari bahan dasar ester fleksibel (dengan tingkat kekerasan 52 Shore D). Sebagai produk unggulan dengan seri MB-Longlife®, selang ini cocok untuk digunakan pada hampir semua aplikasi pneumatik tekanan rendah standar industri.
Keunggulan PU 98 MB-Longlife®
- Memiliki tingkat fleksibilitas yang sangat baik
- Stabilitas dimensi yang bagus dan tidak mudah rusak
- Radius tekukan atau bending radius sangat kecil
- Memiliki ketahanan yang baik terhadap tekukan dan abrasi
- Cocok untuk digunakan pada perangkat atau sistem yang bergerak dengan sangat cepat
- Memiliki banyak pilihan warna untuk kemudahan aplikasi
Dapatkan selang PU 98 MB-Longlife® import Italy hanya di PT. Bawalaksana Central Industrial, distribtor resmi Mebra Plastik Italia.
Silahkan kontak kami untuk mendapatkan informasi detail produk selang PU 98 MB-Longlife dan penawaran terbaik.
Standard lengths
25-50-100 m
Recommended fittings
All types of pneumatic fittings (quick, push in, compression).
Sector
INDUSTRIAL
Applications
INDUSTRIAL AUTOMATION
ROBOTICS
VACUUM
Products & Details
| Part number | Inner diameter (iØ) | Outer diameter (oØ) | Wall thickness | Minimum bending radius | Operating pressure (23°C) | Standard colors |
| PU2X4 | 2 mm | 4 mm | 1 mm | 10 mm | 22 BAR | N A S R G T |
| PU2.3X4 | 2.3 mm | 4 mm | 0.85 mm | 15 mm | 17 BAR | N A T |
| PU2.5X4 | 2.5 mm | 4 mm | 0.75 mm | 15 mm | 15 BAR | N BT VT A S R G T |
| PU3X5 | 3 mm | 5 mm | 1 mm | 20 mm | 16 BAR | N A T |
| PU4X6 | 4 mm | 6 mm | 1 mm | 25 mm | 13 BAR | N BT VT A S BL R AR G T |
| PU5X8 | 5 mm | 8 mm | 1.5 mm | 30 mm | 15 BAR | N A R G T |
| PU5.5X8 | 5.5 mm | 8 mm | 1.25 mm | 40 mm | 12 BAR | N BT VT A BL R G T |
| PU6X8 | 5.7 mm | 8 mm | 1.15 mm | 40 mm | 11 BAR | N BT VT A S R G T |
| PU6.5X10 | 6.5 mm | 10 mm | 1.75 mm | 40 mm | 14 BAR | N A T |
| PU7X10 | 7 mm | 10 mm | 1.5 mm | 50 mm | 11 BAR | N A R G T |
| PU7.5X10 | 7.5 mm | 10 mm | 1.25 mm | 60 mm | 9 BAR | N BT VT A S R G T |
| PU8X10 | 7.7 mm | 10 mm | 1.15 mm | 65 mm | 8 BAR | N BT A S R G T |
| PU8X12 | 8 mm | 12 mm | 2 mm | 50 mm | 13 BAR | N BT A S R T |
| PU9X12 | 9 mm | 12 mm | 1.5 mm | 70 mm | 9 BAR | N BT VT A S R G T |
| PU10X14 | 10 mm | 14 mm | 2 mm | 70 mm | 11 BAR | N A T |
| PU11X14 | 11 mm | 14 mm | 1.5 mm | 100 mm | 8 BAR | N A R T |
| PU11X16 | 11 mm | 16 mm | 2.5 mm | 75 mm | 12 BAR | N A T |
| PU12X16 | 12 mm | 16 mm | 2 mm | 95 mm | 9 BAR | N A R T |
Pressure & temperature
Operating temperature: from -40°C to 60°C
Safety factor on working pressure: 3:1
Working pressure 8-22 BAR (23°C)
