Features
Tubing spiral Nylon P.10 merupakan selang berbahan Polyamide dengan karakteristik kuat, telah diplastisasi dan memiliki stabilitas yang baik terhadap suhu tinggi.
Selang spiral ini merupakan versi lain dari Nylon P.10 di katalog kami dengan tingkat kekerasan 53/63 Shore D.
Selang Nylon P.10 spiral direkomendasikan untuk lingkungan yang terkontrol, di mana tingkat kelembaban dapat dijaga secara konsisten untuk mencegah perubahan dimensi tubing atau kerusakan.
Catatan:
- Selang spiral ini dibuat berdasarkan request sesuai desain dan dapat ditambahkan kabel.
- Jika Anda sedang mencari selang spiral daya tahan tinggi dengan memori elastis kuat, tahan tarik-ulur berulang, puntiran dan kelembapan (hydrolisis resistance), kami merekomendasikan tubing PU Spiral 1190 Extraflex.
- Jika Anda mencari selang spiral untuk truk kontainer dan traktor yang bersertifikat internasional DIN 73373, gunakan Air Brake Spiral Hose PA 12 PHL.
Dapatkan selang spiral Nylon P.10 import Italy harga ekonomis hanya di PT. Bawalaksana Central Industrial.
Kontak tim Sales Engineer kami untuk mendapatkan rekomendasi dan harga terbaik sesuai aplikasi di industri Anda.
Sector
INDUSTRIAL
Applications
INDUSTRIAL AUTOMATION
VACUUM
Products & Details
| Part number | Inner diameter (iØ) | Outer diameter (oØ) | Wall thickness | Standard colors | Material length | Retracted length | Turns n | Tale A | Tale B | winding Ø | outer Ø |
| SNP4X6X30 | 4 mm | 6 mm | 1 mm |
AR
|
30 m | 991 mm | 157 N | 0 mm | 0 mm | 55 mm | 67 mm |
| SNP6X8X30 | 6 mm | 8 mm | 1 mm |
BS
AR
|
30 m | 1035 mm | 123 N | 0 mm | 0 mm | 70 mm | 86 mm |
| SNP8X10X30 | 8 mm | 10 mm | 1 mm |
BS
AR
|
30 m | 1010 mm | 96 N | 0 mm | 0 mm | 90 mm | 110 mm |
Pressure & temperature
Operating temperature: from -20°C to 60°C
Working pressure 9-23 BAR (23°C)
